Found 9 results

Sort by:

APC-F8-OM3

Fiber Indoor/Outdoor Cables Uni Tube, Unarmoured Multi Mode OM3 50 /125, Indoor/Outdoor 8 Core Optical fiber cable

Application

Building interconnection
Campus
Local Area Network

*All images are indicative

Documentation Specifications

APC-F12-OM3

Fiber Indoor/Outdoor Cables Uni Tube, Unarmoured Multi Mode OM3 50 /125, Indoor/Outdoor 12 Core Optical fiber cable

Application

Building interconnection
Campus
Local Area Network

*All images are indicative

Documentation Specifications

APC-F24-OM3

Fiber Indoor/Outdoor Cables Uni Tube, Unarmoured Multi Mode OM3 50 /125, Indoor/Outdoor 24 Core Optical fiber cable

Application

Building interconnection
Campus
Local Area Network

*All images are indicative

Documentation Specifications

APOF-DF-H02SCL

Fiber Drop Cables FTTH 2 CORE DROP CABLE

Up to 2 enhance low water peak single mode fibres in full compliance with ITU-T-G.652.D (also available with G657 SM Fibre and OM1 / OM2 / OM3 & OM4 MM Fibre)
FRP / ARP rod as strength member
Steel wire as integrated messenger wire
LSZH shealth

Application

Drop Cable suitable for aerial application.

Documentation Specifications

APOF-IDF-H02SCL

Fiber Drop Cables FTTH INDOOR 2 CORE DROP CABLE,SM/MM

Up to 2 enhance low water peak single mode fibres in full compliance with ITU-T-G.652.D (also available with G657 SM Fibre and OM1 / OM2 / OM3 & OM4 MM Fibre)
FRP / ARP rod as strength member
Steel wire as integrated messenger wire
LSZH shealth

Application

Drop Cable suitable for aerial application.

Documentation Specifications

APOF-IDF-H01SCL

Fiber Drop Cables FTTH INDOOR 1 CORE DROP CABLE,SM/MM

Up to 2 enhance low water peak single mode fibres in full compliance with ITU-T-G.652.D (also available with G657 SM Fibre and OM1 / OM2 / OM3 & OM4 MM Fibre)
FRP / ARP rod as strength member
Steel wire as integrated messenger wire
LSZH shealth

Application

Drop Cable suitable for aerial application.

*All images are indicative

Documentation Specifications

APOF-DF-H01SCL

Fiber Drop Cables FTTH 1 CORE DROP CABLE,SM/MM

Up to 2 enhance low water peak single mode fibres in full compliance with ITU-T-G.652.D (also available with G657 SM Fibre and OM1 / OM2 / OM3 & OM4 MM Fibre)
FRP / ARP rod as strength member
Steel wire as integrated messenger wire
LSZH shealth

Application

Drop Cable suitable for aerial application.

Documentation Specifications

API-F652D-MCM24

Fiber Drop Cables MICRO CABLE Multitube Design 24 CORE FIBER CABLE,SM/MM

Upto 144 fibers in full compliance with ITU-T-G 652 D (also available with G655 / G656 / G657 SM Fibre and OM1 OM2 / OM3 & OM4 MM Fibre)
Non metallic, anti-buckling FRP rod as Central Strength Member (PE upcoated for 144 F)
Loose buffer tubes fully filled, S-Z Stranded
Rip cords for easy stripping
Insect and Termite resistant PA-12 outer sheath, Orange (also available with PE outer sheath)

Application

Suitable for installation in Micro Duct

*All images are indicative

Documentation Specifications

API-F652D-MCS48

Fiber Drop Cables MICRO CABLE Multitube Design 48 CORE FIBER CABLE,SM/MM

Upto 144 fibers in full compliance with ITU-T-G 652 D (also available with G655 / G656 / G657 SM Fibre and OM1 OM2 / OM3 & OM4 MM Fibre)
Non metallic, anti-buckling FRP rod as Central Strength Member (PE upcoated for 144 F)
Loose buffer tubes fully filled, S-Z Stranded
Rip cords for easy stripping
Insect and Termite resistant PA-12 outer sheath, Orange (also available with PE outer sheath)

Application

Suitable for installation in Micro Duct

*All images are indicative

Documentation Specifications

Product Type	Fiber Cable
Performance Level	Multimode
Fiber Count	8 Fiber
Cable Diameter (mm)	6.5 +/- 0.5
Tensile strength (N) Installation	800
Tensile strength (N) Operating	300
Bending Radius Temporary	10D
Bending Radius Permanent	20D
Installation Temperature	-30° to +70° C
Operating Temperature	-30° to +70° C
Color Coding	Blue* Orange* Green* Brown* Grey* White* Red* Black*
Fiber type	OM3 50 /125

Product Type	Fiber Cable
Performance Level	Multimode
Fiber Count	12 Fiber
Cable Diameter (mm)	6.5 +/- 0.5
Tensile strength (N) Installation	800
Tensile strength (N) Operating	300
Bending Radius Temporary	10D
Bending Radius Permanent	20D
Installation Temperature	-30° to +70° C
Operating Temperature	-30° to +70° C
Color Coding	Blue* Orange* Green* Brown* Grey* White* Red* Black* Yellow* Violet* Pink* Aqua*
Fiber type	OM3 50 /125

Product Type	Fiber Cable
Performance Level	Multimode
Fiber Count	24 Fiber
Cable Diameter (mm)	6.8 +/- 0.5
Tensile strength (N) Installation	800
Tensile strength (N) Operating	300
Bending Radius Temporary	10D
Bending Radius Permanent	20D
Installation Temperature	-30° to +70° C
Operating Temperature	-30° to +70° C
Color Coding	Blue, Orange, Green, Brown, Slate, White, Red, Black Yellow, Violet, Pink, Aqua & Natural
Fiber type	OM3 50 /125

Product Type	Fiber Cable
Performance Level	SM/MM
Fiber Count	2 Fiber
Diameter (mm) Nominal	2.0 X 5.0
Weight (Kg./Km) Nominal	20
Tensile strength (N) Installation	130
Tensile strength (N) Operating	50
Bending Radius Temporary	30
Bending Radius Permanent	50
Installation Temperature	-20° to +70° C
Operating Temperature	-40° to +70° C
Color Coding	Blue* Orange*
RoHS	Compliant

Product Type	Fiber Cable
Performance Level	SM/MM
Fiber Count	2 Fiber
Diameter (mm) Nominal	2.0 X 3.0
Weight (Kg./Km) Nominal	8
Tensile strength (N) Installation	40
Tensile strength (N) Operating	20
Bending Radius Temporary	30
Bending Radius Permanent	50
Installation Temperature	-20° to +70° C
Operating Temperature	-40° to +70° C
Color Coding	Blue* Orange*
RoHS	Compliant
