APPS-SL1000DC

SmartLine RT 1kVA 900W On-Line Single-Phase Double-Conversion UPS

The hot-swap battery design to be easy maintenance in rack mount installation. Suit for the enterprise server room and precious equipment with high reliability and high power quality demand.A True double conversion design online UPS is for commercial devices, enterprise server and high-end equipment. A compact size design to have bigger power density for expected space utilization. Suit for the enterprise server room and precious equipment with high reliability and high power quality demand.

Documentation Specifications

APPS-SL2000DC

SmartLine RT 2kVA 1800W On-Line Single-Phase Double-Conversion UPS

Documentation Specifications

APPS-SL3000DC

SmartLine RT 3kVA 2700W On-Line Single-Phase Double-Conversion UPS

Documentation Specifications

APPS-SL6000DC

SmartLine RT 6kVA 5400W On-Line Single-Phase Double-Conversion UPS

Documentation Specifications

APPS-SL10000DC

SmartLine RT 10kVA 9000W On-Line Single-Phase Double-Conversion UPS

Documentation Specifications

UPS Topology	Double Conversion
Energy Saving	Yes, ECO Mode Efficiency >94%
Nominal Voltage	220/230/240 Vac
Voltage Range	20-300 VAC at 50% load / 180-300 VAC at 100% load
Frequency Range	40 Hz – 70 Hz
Power Factor	0.99
Cold Start	Yes
Cord Length (ft)	10
Cord Length (m)	3
VA	1000 (1.0 kVA)
Watts	900 (0.9 kW)
Power Factor	0.9
Crest Factor	3:1
Outlets - Total	6
Outlet Type	Optional
Overload Protection	100% - 125% load: 10 min, 125% - 150% load: 1 min > 150% load: 3 seconds
Short Circuit Protection	or input fuse / circuit breaker protection
Runtime at Half Load (min)	20
Runtime at Full Load (min)	7.4
Battery Type	Sealed lead acid
Battery Size	12 V/9 Ah
Battery Quantity	2
Replaceable	Yes
Replacement Battery	As per the load capacity
Hot Swappable	Yes
Typical Recharge Time	4 h (0% to 90%)
Rotatable LCD Control Panel	Yes
Software	Available
Smart RS-232/USB	Supports Windows 2000/2003/XP/ Vista/2008/7/8/10, Linux, and MAC
Optional SNMP	Power management from SNMP manager and web browser
Form Factor	Rack / Tower convertible (rotatable LCD)
Enclosure Construction	Steel
Rack Mounting Hardware	Included
Dimensions D x W x H (cm)	44 x 47 x 9
Weight (lb)	26.4
Weight (kg)	12
Rack Units	2U
Storage Temperature	-4 °F to 113 °F (-20 °C to 45 °C)
RoHS Compliance	Compliant

UPS Topology	Double Conversion
Nominal Voltage	220/230/240 Vac
Voltage Range	20-300 VAC at 50% load / 180-300 VAC at 100% load
Frequency Range	40 Hz – 70 Hz
Power Factor	0.99
Cold Start	Yes
Cord Length (ft)	10
Cord Length (m)	3
VA	2000 (2.0 kVA)
Watts	1800 (1.8 kW)
Power Factor	0.9
Crest Factor	3:1
Outlets - Total	8
Outlet Type	Optional
Overload Protection	100% - 125% load: 10 min, 125% - 150% load: 1 min > 150% load: 3 seconds
Short Circuit Protection	Input fuse / circuit breaker protection
Runtime at Half Load (min)	20
Runtime at Full Load (min)	6.5
Battery Type	Sealed lead acid
Battery Size	12 V/9 Ah
Battery Quantity	4
Replaceable	Yes
Replacement Battery	As per the load capacity
Hot Swappable	Yes
Typical Recharge Time	4 h (0% to 90%)
Rotatable LCD Control Panel	Yes
Software	Available
Smart RS-232/USB	Supports Windows 2000/2003/XP/ Vista/2008/7/8/10, Linux, and MAC
Optional SNMP	Power management from SNMP manager and web browser
Form Factor	Rack / Tower convertible (rotatable LCD)
Enclosure Construction	Steel
Rack Mounting Hardware	Included
Dimensions D x W x H (cm)	44 x 66 x 9
Weight (lb)	50.7
Weight (kg)	23
Rack Units	2U
Energy Saving	Yes, ECO Mode Efficiency >94%
Storage Temperature	-4 °F to 113 °F (-20 °C to 45 °C)
RoHS Compliance	Compliant

UPS Topology	Double Conversion
Energy Saving	Yes, ECO Mode Efficiency >94%
Nominal Voltage	220/230/240 Vac
Voltage Range	20-300 VAC at 50% load / 180-300 VAC at 100% load
Frequency Range	40 Hz – 70 Hz
Power Factor	0.99
Cold Start	Yes
Cord Length (ft)	10
Cord Length (m)	3
VA	3000 (3.0 kVA)
Watts	2700 (2.7 kW)
Power Factor	0.9
Crest Factor	3:1
Outlets - Total	8
Outlet Type	Optional
Overload Protection	100% - 125% load: 10 min, 125% - 150% load: 1 min > 150% load: 3 seconds
Short Circuit Protection	Input fuse / circuit breaker protection
Runtime at Half Load (min)	11
Runtime at Full Load (min)	3.5
Battery Type	Sealed lead acid
Battery Size	12 V/9 Ah
Battery Quantity	6
Replaceable	Yes
Replacement Battery	As per the load capacity
Hot Swappable	Yes
Typical Recharge Time	4 h (0% to 90%)
Rotatable LCD Control Panel	Yes
Software	Available
Smart RS-232/USB	Supports Windows 2000/2003/XP/ Vista/2008/7/8/10, Linux, and MAC
Optional SNMP	Power management from SNMP manager and web browser
Form Factor	Rack / Tower convertible (rotatable LCD)
Enclosure Construction	Steel
Rack Mounting Hardware	Included
Dimensions D x W x H (cm)	44 x 66 x 9
Weight (lb)	66.1
Weight (kg)	30
Rack Units	2U
Storage Temperature	-4 °F to 113 °F (-20 °C to 45 °C)
RoHS Compliance	Compliant

UPS Topology	Double Conversion
Energy Saving	Yes, ECO Mode Efficiency >94%
Nominal Voltage	220/230/240 Vac
Voltage Range	20-300 VAC at 50% load / 180-300 VAC at 100% load
Frequency Range	40 Hz – 70 Hz
Power Factor	0.99
Cold Start	Yes
Cord Length (ft)	10
Cord Length (m)	3
VA	6000 (6.0 kVA)
Watts	5400 (5.4 kW)
Power Factor	0.9
Crest Factor	3:1
Outlets - Total	8
Outlet Type	Optional
Overload Protection	100% - 125% load: 10 min, 125% - 150% load: 1 min > 150% load: 3 seconds
Short Circuit Protection	Input fuse / circuit breaker protection
Runtime at Half Load (min)	15
Runtime at Full Load (min)	4.5
Battery Type	Sealed lead acid
Battery Size	12 V/9 Ah
Battery Quantity	16
Replaceable	Yes
Replacement Battery	As per the load capacity
Hot Swappable	Yes
Typical Recharge Time	4 h (0% to 90%)
Rotatable LCD Control Panel	Yes
Software	Available
Smart RS-232/USB	Supports Windows 2000/2003/XP/ Vista/2008/7/8/10, Linux, and MAC
Optional SNMP	Power management from SNMP manager and web browser
Form Factor	Rack / Tower convertible (rotatable LCD)
Enclosure Construction	Steel
Rack Mounting Hardware	Included
Dimensions D x W x H (cm)	44 x 58 x 14
Weight (lb)	40.0
Weight (Kg)	20
Rack Units	3U
Storage Temperature	-4 °F to 113 °F (-20 °C to 45 °C)
RoHS Compliance	Compliant

UPS Topology	Double Conversion
Energy Saving	Yes, ECO Mode Efficiency >94%
Nominal Voltage	220/230/240 Vac
Voltage Range	20-300 VAC at 50% load / 180-300 VAC at 100% load
Frequency Range	40 Hz – 70 Hz
Power Factor	0.99
Cold Start	Yes
Cord Length (ft)	10
Cord Length (m)	305
VA	10000 (10.0 kVA)
Watts	9000 (9.0 kW)
Power Factor	0.9
Crest Factor	3:1
Outlets - Total	8
Outlet Type	Optional
Overload Protection	100% - 125% load: 10 min, 125% - 150% load: 1 min > 150% load: 3 seconds
Short Circuit Protection	Input fuse / circuit breaker protection
Runtime at Half Load (min)	10
Runtime at Full Load (min)	4.5
Battery Type	Sealed lead acid
Battery Size	12 V/9 Ah
Battery Quantity	16
Replaceable	Yes
Replacement Battery	As per the load capacity
Hot Swappable	Yes
Typical Recharge Time	4 h (0% to 90%)
Rotatable LCD Control Panel	Yes
Software	Available
Smart RS-232/USB	Supports Windows 2000/2003/XP/ Vista/2008/7/8/10, Linux, and MAC
Optional SNMP	Power management from SNMP manager and web browser
Form Factor	Rack / Tower convertible (rotatable LCD)
Enclosure Construction	Steel
Rack Mounting Hardware	Included
Dimensions D x W x H (cm)	44 x 58 x 14
Weight (lb)	48.5
Weight (kg)	22
Rack Units	3U
Storage Temperature	-4 °F to 113 °F (-20 °C to 45 °C)
RoHS Compliance	Compliant
