The hot-swap battery design to be easy maintenance in rack mount installation. Suit for the enterprise server room and precious equipment with high reliability and high power quality demand.A True double conversion design online UPS is for commercial devices, enterprise server and high-end equipment. A compact size design to have bigger power density for expected space utilization. Suit for the enterprise server room and precious equipment with high reliability and high power quality demand.
| UPS Topology | Double Conversion |
| Energy Saving | Yes, ECO Mode Efficiency >94% |
| Nominal Voltage | 220/230/240 Vac |
| Voltage Range | 20-300 VAC at 50% load / 180-300 VAC at 100% load |
| Frequency Range | 40 Hz – 70 Hz |
| Power Factor | 0.99 |
| Cold Start | Yes |
| Cord Length (ft) | 10 |
| Cord Length (m) | 305 |
| VA | 10000 (10.0 kVA) |
| Watts | 9000 (9.0 kW) |
| Power Factor | 0.9 |
| Crest Factor | 3:1 |
| Outlets - Total | 8 |
| Outlet Type | Optional |
| Overload Protection | 100% - 125% load: 10 min, 125% - 150% load: 1 min > 150% load: 3 seconds |
| Short Circuit Protection | Input fuse / circuit breaker protection |
| Runtime at Half Load (min) | 10 |
| Runtime at Full Load (min) | 4.5 |
| Battery Type | Sealed lead acid |
| Battery Size | 12 V/9 Ah |
| Battery Quantity | 16 |
| Replaceable | Yes |
| Replacement Battery | As per the load capacity |
| Hot Swappable | Yes |
| Typical Recharge Time | 4 h (0% to 90%) |
| Rotatable LCD Control Panel | Yes |
| Software | Available |
| Smart RS-232/USB | Supports Windows 2000/2003/XP/ Vista/2008/7/8/10, Linux, and MAC |
| Optional SNMP | Power management from SNMP manager and web browser |
| Form Factor | Rack / Tower convertible (rotatable LCD) |
| Enclosure Construction | Steel |
| Rack Mounting Hardware | Included |
| Dimensions D x W x H (cm) | 44 x 58 x 14 |
| Weight (lb) | 48.5 |
| Weight (kg) | 22 |
| Rack Units | 3U |
| Storage Temperature | -4 °F to 113 °F (-20 °C to 45 °C) |
| RoHS Compliance | Compliant |
| Part Number | Description |
| APPS-SL10000DC | 10kVA 9000W On-Line Single-Phase Double-Conversion UPS |
| UPS Topology | Double Conversion |
| Energy Saving | Yes, ECO Mode Efficiency >94% |
| Nominal Voltage | 220/230/240 Vac |
| Voltage Range | 20-300 VAC at 50% load / 180-300 VAC at 100% load |
| Frequency Range | 40 Hz – 70 Hz |
| Power Factor | 0.99 |
| Cold Start | Yes |
| Cord Length (ft) | 10 |
| Cord Length (m) | 305 |
| VA | 10000 (10.0 kVA) |
| Watts | 9000 (9.0 kW) |
| Power Factor | 0.9 |
| Crest Factor | 3:1 |
| Outlets - Total | 8 |
| Outlet Type | Optional |
| Overload Protection | 100% - 125% load: 10 min, 125% - 150% load: 1 min > 150% load: 3 seconds |
| Short Circuit Protection | Input fuse / circuit breaker protection |
| Runtime at Half Load (min) | 10 |
| Runtime at Full Load (min) | 4.5 |
| Battery Type | Sealed lead acid |
| Battery Size | 12 V/9 Ah |
| Battery Quantity | 16 |
| Replaceable | Yes |
| Replacement Battery | As per the load capacity |
| Hot Swappable | Yes |
| Typical Recharge Time | 4 h (0% to 90%) |
| Rotatable LCD Control Panel | Yes |
| Software | Available |
| Smart RS-232/USB | Supports Windows 2000/2003/XP/ Vista/2008/7/8/10, Linux, and MAC |
| Optional SNMP | Power management from SNMP manager and web browser |
| Form Factor | Rack / Tower convertible (rotatable LCD) |
| Enclosure Construction | Steel |
| Rack Mounting Hardware | Included |
| Dimensions D x W x H (cm) | 44 x 58 x 14 |
| Weight (lb) | 48.5 |
| Weight (kg) | 22 |
| Rack Units | 3U |
| Storage Temperature | -4 °F to 113 °F (-20 °C to 45 °C) |
| RoHS Compliance | Compliant |
| Part Number | Description |
| APPS-SL10000DC | 10kVA 9000W On-Line Single-Phase Double-Conversion UPS |
