APWM-6618D

18U Double Section Wall Mount Cabinet with Glass Front Door

The Wall Mount Server Cabinet is designed to house EIA-standard 19-inch rack equipment in network wiring closets, retail locations, classrooms, back offces and other areas with limited floor space where you need equipment to be secure, organized and out of the way. Constructed from heavy-duty steel with a durable black powder-coated finish, the cabinet has a maximum load capacity of 198 lbs.

Product TypeDouble Section Wall cabinet
No. of Rack Spaces18U
Maximum Height900mm
Maximum Depth600mm
Maximum Width800mm
ColorBlack RAL 9004 ( Gray RAL 7035 Optional )
Front DoorGlass
Rear DoorSPCC
Side PanelSPCC
Static Load Capacity198.4lbs( 90Kg )
Grounding WireFront door frames
CECompliant
RoHSCompliant

Data Sheet
Download : 4,540.46 KB Format : pdf Modified : 28-11-22
CE
Download : 233.90 KB Format : pdf Modified : 28-11-22
RoHS
Download : 633.87 KB Format : pdf Modified : 28-11-22

Part NumberDescription
APWM-6618D18U 600*600 Double Section Wall Mount Cabinet with Glass Front Door
APWM-6818D18U 600*800 Double Section Wall Mount Cabinet with Glass Front Door

Specifications

Product TypeDouble Section Wall cabinet
No. of Rack Spaces18U
Maximum Height900mm
Maximum Depth600mm
Maximum Width800mm
ColorBlack RAL 9004 ( Gray RAL 7035 Optional )
Front DoorGlass
Rear DoorSPCC
Side PanelSPCC
Static Load Capacity198.4lbs( 90Kg )
Grounding WireFront door frames
CECompliant
RoHSCompliant

Manuals & Warranties

Data Sheet
Download : 4,540.46 KB Format : pdf Modified : 28-11-22
CE
Download : 233.90 KB Format : pdf Modified : 28-11-22
RoHS
Download : 633.87 KB Format : pdf Modified : 28-11-22

Ordering Information

Part NumberDescription
APWM-6618D18U 600*600 Double Section Wall Mount Cabinet with Glass Front Door
APWM-6818D18U 600*800 Double Section Wall Mount Cabinet with Glass Front Door
