Network cabinets are generally used for the storage of routers, patch panels, switches and a wide variety of networking equipment as well as networking accessories. In most cases a network cabinet will be far shallower than a server rack cabinet, generally measuring in at less than thirty one inches deep.
| Product Type | Floor standing cabinet |
| No. of Rack Spaces | 22U |
| Material | SPCC |
| Loading Capacity | 800kg (on the adjustable feet) |
| Degree of protection | IP20 |
| Surface finish | Degreasing,Pickling,Phosphating,Powder Coated |
| Width | 600mm,800mm |
| Depth | 600mm,800mm,900mm,1000mm,1200mm |
| Standard | ANS/EIA RS-310-D,IEC297-2,DIN41491,PART1,DIN41491,PART7,ETSI Standard |
| Compliants | CE,RoHS |
| Color | Ral9004; Ral9005; Ral7035 |
| Part Number | Description |
| APFS-6622 | 22U 600*600 FLOOR STANDING CABINET WITH FRONT MESH DOOR BELT,DOUBLE PERFORATED REAR DOOR |
| APFS-6822 | 22U 600*800 FLOOR STANDING CABINET WITH FRONT MESH DOOR BELT,DOUBLE PERFORATED REAR DOOR |
| APFS-8822 | 22U 800*800 FLOOR STANDING CABINET WITH FRONT MESH DOOR BELT,DOUBLE PERFORATED REAR DOOR |
| APFS-8122 | 22U 800*1000 FLOOR STANDING CABINET WITH FRONT MESH DOOR BELT,DOUBLE PERFORATED REAR DOOR |
| Product Type | Floor standing cabinet |
| No. of Rack Spaces | 22U |
| Material | SPCC |
| Loading Capacity | 800kg (on the adjustable feet) |
| Degree of protection | IP20 |
| Surface finish | Degreasing,Pickling,Phosphating,Powder Coated |
| Width | 600mm,800mm |
| Depth | 600mm,800mm,900mm,1000mm,1200mm |
| Standard | ANS/EIA RS-310-D,IEC297-2,DIN41491,PART1,DIN41491,PART7,ETSI Standard |
| Compliants | CE,RoHS |
| Color | Ral9004; Ral9005; Ral7035 |
| Part Number | Description |
| APFS-6622 | 22U 600*600 FLOOR STANDING CABINET WITH FRONT MESH DOOR BELT,DOUBLE PERFORATED REAR DOOR |
| APFS-6822 | 22U 600*800 FLOOR STANDING CABINET WITH FRONT MESH DOOR BELT,DOUBLE PERFORATED REAR DOOR |
| APFS-8822 | 22U 800*800 FLOOR STANDING CABINET WITH FRONT MESH DOOR BELT,DOUBLE PERFORATED REAR DOOR |
| APFS-8122 | 22U 800*1000 FLOOR STANDING CABINET WITH FRONT MESH DOOR BELT,DOUBLE PERFORATED REAR DOOR |
